Most Powerful Loaders from Bobcat – R-Series S86 and T86

The new S86 R-Series Skid-Steer Loader and T86 R-Series Compact Track Loader replace the previous 700 and 800 M-Series loaders and complete the current R-Series loader line-up. Delivering a higher engine and hydraulic output, the Bobcat S86 and T86 are the most powerful compact loaders the company has ever built. Both machines use a well-proven Stage V compliant 3.4 l Bobcat engine – producing 78 kW (105 HP) at 2600 RPM.

One of the most exciting new aspects of the S86 and T86 is that both machines have for the first time three different auxiliary flow outputs. There is a standard flow configuration providing 87 l/min for applications such as load and carry, or where low hydraulic flow attachments are used. Bobcat also offers two additional hydraulic performance functions using the new Electronic Displacement Control (EDC) Pump: a High Flow function giving 138 l/min and a new, industry unique Super Flow function taking auxiliary flow to 159 l/min.

The Super Flow function typically increases productivity with like-for-like attachments by 15 to 20%, and it has a new 5-coupler connection block allowing the use of larger ¾ inch quick coupler connectors and ¾ inch attachment hoses. This change also helps increase auxiliary hydraulic efficiency and performance.

Bobcat Innovations and Technologies

Concept – Quad Tracks – Bauma Innovation Award Finalist

Currently being tested in markets in the USA, the Quad Track concept allows the wheels of selected Bobcat skid-steer loaders to be easily replaced with four individual track pods, effectively converting them into tracked loaders.

Chosen as one of the finalists in the Mechanical Engineering category of the Bauma 2022 Innovation Awards, Bobcat quad tracks add considerable versatility to skid-steer loaders, allowing them to easily adapt to different environments. Benefits include increased flotation, reduced ground pressure and better traction on wet ground, compared to traditional wheeled skid-steer loaders, with a smoother ride compared to two-track compact track loaders.

The Bobcat quad track solution allows the conversion of a wheeled skid-steer loader to a quad track loader simply by removing the wheels, adding an oscillation bar to limit total oscillation, and attaching track pods to the existing axles. The machine can easily be converted back to a wheeled loader, when desired.

The ground pressure exerted by the quad track loader falls between that of the comparable skid-steer and compact track loaders. This provides even better forces when excavating soil, pushing snow or in other applications where a high push force is required compared to skid-steer loaders.

Whilst quad tracks are a known technology, they have not been used before on skid-steer loaders, which require a track system that can withstand side-to-side movements, as well as forward and backward, which is introduced in skid-steering.

 Concept – OLED Transparent Touch Display

The Bobcat Transparent Touch Display concept has been developed in conjunction with LG Electronics and BSI Research and utilises OLED (Organic Light Emitting Diode) technology. This new system provides a transparent, engaging touch display solution embedded within the glass structure of the operator’s cab to enhance their productivity, efficiency and visibility of the task at hand. The display can be positioned on the front windshield or side window of the cab on a range of Bobcat machines, including mini-excavators, telehandlers and loaders.

The operator can customize the display with smart widgets and interactive applications, to integrate data relevant to the jobsite or daily activities. This transparent, multi-function display allows an operator to view vital information and machine data displayed on the OLED screen and simply refocus their vision to see everything that is going on around them on the worksite.
